Model No.

YDQG12LF

General

Main processor

Ingenic-T31ZL

APP Operation System

Android, IOS

Image Senor

1/2.7″ Image Sensor

Compression

H.264+/H.265

Resolution

1920*1080 1080P

Internet Connection

4G

TD-LTE,TD-LTE / LTE FDD TD-LTE / LTE-FDD

4G Version

CN/ AU/ EU/ JP/ US/ ASEAN (Optional)

Alarm

Detection Mode

PIR Human detection + AI Human shape detection

Detection Distance

0~12M

Detect Angle

105°

Alarm Mode

Realtime calling or push message

PTZ

PTZ Angle

Horizontal 355 ° Vertica 100°

Speed

Horizontal 55 °/S Vertical 40°/S

Night Vision

Full color night vision

0.001 Lux

IR LED

infrared LED 25M IR distance

White light LED

white light LED 25M distance

 Audio

Built-in speaker (input)

3W

Built-in microphone (output)

voice monitoring distance 20M

Lens

Lens

3.6mm

Lens Angle

95°

Storage

Cloud Storage

Cloud storage, storage when alarm recording

Local Storage

TF Card Max 128G

Power

Power Supply Mode

Solar Panel+ Build in Batteries

Panel Material

monocrystalline silicon

Solar Energy Power

8W

Battery Capacity

Build in 6pcs 21700 battery ( 15600MAH  )

Operating power consumption

Max 3W

Standby consumption

0.003W

Others

Working Environment

Indoor/outdoor

Operation Temperature

-30°~+60°

Humidity

0%~90%RH
