System

Main Processor

32-BIT RISC Master

Operating system

Linux

Image Sensor

Sensor

CMOS sensor 1/3''

Pixel

2560*1440p

Minimum illumination

0.1LUX/F1.2

Lens

Lens parameters

Focal length: 4mm, viewing angle；110°

Battery

Battery specification

2*5000mha battery pack(built-in)

Standby time

10000mha batteries standby for around 6 months

Standby current

Less than 1mA

Wake up time

About 6000times

Charging input

Base station auto recharging; power adapter Type C DC5V

Video

Resolution

Main stream : 2560*1440, Sub stream: 640*360

Compression format

H.264

Frame frequency

20fps

Exposure

auto exposure white balance

WDR

Digital WDR

IR-CUT

No color cast during the day, super-clear night vision

Zoom

app supports 3x digital zoom

Light

Infrared mode

Infaraed night vision

White light mode

At night, the white light is turned on, the brightness is adjustable, full color night vision

Night Vision

Infrared night vision

support

Color night vision

turn on full-color night vision in dark environment

Alarm mode

when there is no one at night, the infrared light will be on when accessing through app; if someone triggers the pir, the white light will be on

Audio

Protocol

G711U

Function

Built-in microphone and speaker , support monitoring and intercom

Storage

TF Card

support max up to 128G TF card

Record standard

1440p

Record mode

 pir trigger

Playback

support remote video playback

Network

Wireless

2.4G (11BNG) MIXED

Distribution mode

QR Code distribution network

User online

Number of simultaneous online viewers, 5 people are supported at the same time

Privacy Protection

Privacy Protection

the system defaults that the first added user is the administrator. And other users need to be authorized to access

Privacy Block

Support 4 optional private area, increase privacy protection

Alarm

Alarm

Human body induction alarm (PIR)

Alarm notification

Mobile phone push alarm

PTZ

Support

Pan 360°， Tilt ：45°

PIR

Support

Default start time is from 20:00~7:00(User can set)

APP

Smart APP

Support android and ios

Others

Power type

Battery Camera

Power interface

Type C DC5V

Working temperature

-10°C ~ 50°C

Working power consumption

1.5~5w (daytime 1.5w)

Standby power consumption

Less than 0.003w

Working humidity

10%~90% RH

Certificate

Certificates

Rosh、Reach、FCC、CE
