Products Features

Resolution

2MP(1920x1080)

System

Embeded linus real-tiem operating system

Night Vision

IR Leds

Denoise

3D

Fixed lens

2.8mm

FOV

120°

Aperture

F2.0

Image compression

H.265/H.264/MJPEG

Image frame rate

Main Stream：: 1920*1080@15fps；Sub Stream: 640*360@15fps

Video bitrate

Main Stream：1.0Mbps；Sub Stream：512Kbps

Functions

Multi-channels preview

Maximum support 2 channels P2P，synchronized previewing at mutilple terminals

Imagine Flip

Support horizontal and vertical flip

Audio input

1*Microphone

Audio output

1*Speaker

Two-way audio

Support bidirectional video intercom at anytime and anywhere

Audio Processing

G.711 coding staandarrd, support audio and video synchronization

PTZ function

Pan: 0°~355°, Tilt: 0°~65°

Alarm detection

Motion detection/ human detection

Motion tracking

YES

Regional alert

Support regional alarm settings

Alarm sensitivity

Support low/medium/high settings

AI Functions

Support Human tracking/Motion detection /Sound detection

Recording Mode

Event /manual/timed/ Non-stop recording

W/D

Support digital and vertical flip

Timed screen off

App can set a timer to turn off the screen

Playback

YES

Cloud storage

YES

Interfaces and Buttons

Call button

YES

Hang up button

YES

Reset button

YES

SD card Slot

TF card / SD cardx Monitor card , and C10 UP better

Power port

Micro-USB

Onvif

NO

Power input

DC5V/2A

Others

WIFI protocal

Wi-Fi IEEE 802.11 b/g/n 2.4 GHz

Bluetooth

Support

Operating conditional

-10°C(14°F)～45°C(113°F), ≤95% RH

Connection mode

Bluetooth mode / Scan qr code

APP Introduce

Tuya smart / Smart life / other oem app based on tuya IOT

Local Storage

4G /8G/ 16G /32G/ 64G /128G TF /SD card

Cloud storage

Paid project by tuya platform

Mounting Types

Seat

Certificates

Rosh、Reach、FCC、CE
