Model No. |
YDQG11LF(Plastic +Metal housing) |
||
General |
Resolution |
2MP |
4MP |
1920*1080 |
2592*1520 |
||
Main processor |
Ingenic-T31ZL |
Ingenic-T31ZX |
|
Image Senor |
GC2063 |
GC4653 |
|
APP Operation System |
Android, IOS |
||
Compression |
H.264+/H.265 |
||
Internet Connection |
4G |
TD-LTE,TD-LTE / LTE FDD TD-LTE / LTE-FDD |
|
4G Version |
CN/ AU/ EU/ JP/ US/ ASEAN (Optional) |
||
Alarm |
Detection Mode |
PIR Human detection + AI Human shape detection |
|
Detection Distance |
0~12M |
||
Detect Angle |
95° |
||
Alarm Mode |
Realtime calling or push message |
||
PTZ |
PTZ Angle |
Horizontal 355 ° Vertica 100° |
|
Speed |
Horizontal 55 °/S Vertical 40°/S |
||
Night Vision |
Full color night vision |
0.001 Lux |
|
IR LED |
infrared LED 25M IR distance |
||
White light LED |
white light LED 25M distance |
||
Audio |
Built-in speaker (input) |
3W |
|
Built-in microphone (output) |
voice monitoring distance 20M |
||
Lens |
Lens |
3.6mm |
|
Lens Angle |
95° |
||
Storage |
Cloud Storage |
storage when alarm recording |
|
Local Storage |
TF Card Max 128G |
||
Power |
Power Supply Mode |
Solar Panel+ Build in Batteries |
|
Panel Material |
monocrystalline silicon |
||
Solar Energy Power |
8W |
||
Battery Capacity |
Support 6pcs 18650 batteries(6*3000MA=18000MA) |
||
Operating power consumption |
4W |
||
Standby consumption |
0.003W |
||
Others |
Working Environment |
Indoor/outdoor |
|
Operation Temperature |
-30°~+60° |
||
Humidity |
0%~90%RH |
